Dinstar DAG1000 4 Port FXS and 4 Port FXO VoIP Gateway

These connect the analog phone system to the PSTN fixed transmission lines at the same time. It comes with a SIP account that supports both primary and secondary protocols. Flexible FXO port modules are also included with the unit. The gateway also has a caller ID with several SIP trunks. The device's high-end versatility is provided by the use of manipulation and routing rules. The DAG2000-4S40 gateway hybrid device provides excellent VLAN administration, as well as data and voice control.

Share this Product:

Security policy

Call US 12/6 +91 922 222 8181

Call us for info on stock / delivery / pricing Details.

Delivery policy

Live Whatsapp  +91 922 222 8989

Whatsapp Live agent for immediate Purchase Support.

Return policy

Dealer Helpline +91 922 222 1378

Exclusive Dealer helpline for Purchase Queries / Support.


Free Shipping

On all orders over $500


Free Returns

Returns are free within 7 days


Support 24/7

Contact us 24 hours a day


100% Secure Payment

Your payment is safe with us



For flexibility interoperability, the DAG1000-4S40 unit uses RJ-11, 4FSX, and 4FSO interfaces. Echo cancellation, SIPv2 protocol, NAT traversal with both dynamic and static transmissions, and other functions are included in the device. DTMF and pulse dialling modes are also included in the device’s dialing modes. A busy tone for caller ID, current detection, and polarity reversal detection have also been implemented. The DAG2000’s entry unit can also support open-standard SIP with IPv4 and IPv6 arrange convention support. It comes with a cabling length of up to 3 kilometers.

This site is fully compatible with driving SIP-based IP communication stages and NGN/IMS frameworks, thanks to Broadsoft/Elastix accreditation. An agreeable commotion era is acknowledgeable with the DAG2000-4S4O FXS Analog VoIP unit. In addition, the device has a quiet concealing feature that keeps the voice clean and fresh. VAD, or voice action location, is another distinct feature of this device that helps with reverberation cancellation. A jitter cushion with a programmable pickup control is also included in the device.


  • Cost-effective gateway with 4 FXO ports.
  • Support IPv4 and IPv6.
  • Elastix/ Broadsoft Certification.
  • Multiple codecs: G.711A/U, G.723.1, G.729A/B, etc.
  • SIP-based IP telephony system is fully compatible with Leading IMS/NGN.


Buy Dinstar DAG1000 4 Port FXS and 4 Port FXO VoIP Gateway | AcmaTel Communications

Do you want to talk to one of our Telephony experts about your project?

Please feel free to fill out our Inquiry Form if you have any telephony solutions that you’d want to discuss. Within the following 12 working hours, one of our business experts will contact you.

Product Tags:

Product Specification


FXO port
Dialing Modes Pulse and DTMF
Pulse Dialing 10 and 20 PPS
Busy Tone/No Current Detection, Polarity Reversal Detection Yes
Caller ID DTMF, Bellcore Type 1&2, ETSI, BT, NTT
Lifeline Power/Network Failure Lifeline
FXS Port
Caller ID DTMF and FSK Presentation
Polarity Reversal for Call Connect/Disconnection Signaling
Dialing Modes Pulse and DTMF
Hook Flash Local or Relay processing
Dimension 242(L)*152(W)*40(H) mm
Humidity 10%-90% Non-condensation
Weight 1.0kg
Temperature (Operation):-10 ℃~ 45 ℃ (Storage): -20 ℃~80 ℃
Physical Interfaces
Ethernet Interface 4*RJ-45 10/100 Base-Tx, RJ-45
Telephone interface 4FXS, 8FXS, RJ-11
Power Supply
Power Consumption (Typical): 20W
Input 12VDC 2A, Power Adapter
Supplement Service
Blind Transfer Yes
3-way conference Yes
Attend Transfer Yes
Call Forward on Busy Yes
Call Forward on No Reply Yes
Call Hold Yes
Call Pickup Yes
Call Waiting Yes
Hotline Yes
Unconditional Call Forward Yes
Voicemail Yes
Voice and Fax
Codecs G.711A/U law, G.723.1, G.729A/B
DTMF Signal, RFC2833, INBAND
NAT Traversal STUN, Dynamic/Static NAT
Echo Cancellation G.168 with up to 128ms
FAX T.38, Pass-through
Protocol : SIPv2, SDP, RTP (RFC2833)
QoS VLAN 802.1P/Q, DIFFServ ToS
