Description
Akuvox VP-R49P Video IP Phone’s video terminal has all of the essential features, including two Ethernet ports, Bluetooth, USB, and PoE support. The Akuvox VP-R49P supports H.264 / H.263 codecs with adaptive bandwidth control, as well as SIP RFC3261, TCP / UDP / IP, PPPoE, RTP / RTCP, HTTP / HTTPS, and other modern IP-telephony standards. The Akuvox VP-R49P IP videophone will be an excellent tool for employees and managers due to its rich functionality, ease of use, and elegant design, allowing them to conduct video conferences and exchange high-quality content. The Akuvox VP-R49P video terminal has a 7-inch TFT LCD capacitive touchscreen display with 1024 * 600 pixels and a 5M CMOS camera, allowing users to exchange high-quality video. Not only does a videophone provide excellent video quality, but it also allows for easy Internet browsing, the use of various programs, and the completion of all necessary daily tasks. The Android operating system enables you to use not only pre-installed apps but also to download new ones from the Google Play Market.
Features of Akuvox VP-R49P
- 7-inch capacitive touch screen TFT LCD with a resolution of 1024 * 600 pixels.
5M pixel CMOS camera with privacy shutter.
- Dual 10/100 Mbps Ethernet, Bluetooth, USB, PoE switch, and wireless.
- Android 4.2 operating system; Android API support for installing third-party Android apps.
- Voice and video codecs: PCMA, PCMU, G.722, G.723, G.729, OPUS, Ilbc, AMR-NB, AMR-WB, H.263, H.264.
- Protocols: SIP RFC3261, TCP / UDP / IP, PPPoE, RTP / RTCP, HTTP / HTTPS, etc .
- Autofocus: FTP / TFTP / HTTP / HTTPS.
Would you like to discuss your project with one of our telephony experts?
If you have any questions about telephony solutions, don’t hesitate to fill out our Inquiry Form. One of our business specialists will get in touch with you within the next 12 working hours.
Product Tags:
Product Specification
Akuvox VP-R49P
The VP-R49P is a SIP-based IP video phone for small and medium-sized businesses with a 7? touch screen, a 5M CMOS camera sensor, and an Android operating system (OS). This multimedia terminal combines a variety of business services, such as high-definition audio and video calling, smooth internet surfing, daily information display, and individualized business applications import from one’s mobile phone. The benefits of having everything on one screen and a customized work mode for communication and business productivity are immeasurable.
| Video Features |
Codec: H.263 and H.264 | Solution: QCIF, CIF, VGA, 4CIF and 720P | Bitrate: 64kbps-2Mbps | Adaptive bandwidth adjustment | Image format: JPEG, GIF, PNG, and BMP | Other features: PIP, full screen and local video ON/OFF control |
| Interface Features |
2xRJ45 10/100M Ethernet ports | Bluetooth | Wireless access: 802.11b/g/n | 1xUSB flash drive 2.0 | 1xRJ9 handset | 1×3.5mm headset jack | 1xHDMI video output port |
| Audio Features |
Wideband codec: G.722 | Narrowband codec: PCMA, PCMU, G.723, G.729, OPUS, ILBC, AMR-NB, and AMR-WB | Echo cancellation | Voice activity detection | Comfort noise generator | Full-duplex speakerphone | DTMF modes: RFC2833, In-Band, SIP INFO, and Auto |
| Security Features |
Support HTTPS (SSL) | Unterstützung von SRTP für Voice Data Encryption |Support-Login für Administration | SIP Over TLS |
| Network and Security Features |
SIP v2 (RFC3261) | NAT transverse: STUN mode | IP configuration: static IP or DHCP | DTMF mode: In-Band, RFC2833, SIP INFO | HTTP/HTTPS web server für management | Proxy mode und peer-to-peer SIP link mode | NTP für auto time setting | UDP/TCP/DNS-SRV (RFC 3263) | TFTP/FTP/HTTP/HTTPS protocols | 802.1Q VLAN | Unterstützung von HTTPS (SSL) | Unterstützung von SRTP für voice data encryption | Support login für administration | Open VPN, IEEE802.1X | Digest authentication using MD5/MD5-sess | AES encryption für configuration file | SIP over TLS |
| Telefon Features |
Android 4.2 Operation System | Unterstützung von 6 SIP accounts | Anruf Waiting | Anruf Transfer | Anruf Hold | Mute | Redial | Speed Dial | Direct IP Anruf | 6 Wege Konferenz | DND(Do Not Disturb) | Volume Adjustable | Ring Tones Selectable | Multi-Languages Unterstützung von | Default Apps: Phonebook | Weather | Google Play | Digital Photo Frame | Stock | News Feeds | Calendar | World Clock | Alarm Clock, Email, Camera, File Browser | Games |3rd Party Android Applications |
| Directory Features |
Local phonebook: up to 3,000 groups | Phonebook with contacts picture | Favorites | Blacklist | Call log: 600 entries (200 missed calls; 200 dialed calls; 200 received calls.) | LDAP | Intelligent search method |
| SIP Features |
SIP v2 (RFC3261) | Line: 6 SIP accounts |
| Management |
Firmware Local | Update:USB Flash Disk | Firmware Remote | Update: FTP method | Auto Provisioning Using FTP/TFTP/HTTP/HTTPS | System Log Export | Restore To Factory Default | Configuration Managements Via LCD |
| Admin Features |
Firmware local update: web/TF Card/USB flash disk method | Firmware remote update: FTP method | Auto provisioning: FTP/TFTP/HTTP/HTTPS | System log export support | Restore to Factory Default support | Configuration management: touch screen-based management | Multi-language support |
| Physical Features |
Physical Features | 7″ capacitive touch screen | Display: TFT LCD, 1000×600 pixels, 16:9 aspect ratio | LED light: 1 power light, 1 network light and 1 message light | 5 Keys | RK3066 chipset | Flash memory: 8GB | 1GB DDR3 memory | Foot stand | Camera: 5M-pixel CMOS sensor, free rotation | PoE IEEE802.3af | Power adapter: input-AC 100~240V, output-DC 12V/1.0A | Power consumption: approx.14W | Operating temperature: 32~104F (0~40C) | Storage temperature: -4~ 158F (-20 ~ 70C) | Operating humidity: 10% ~90% (non-condensing) | Storage humidity: 10% ~ 90% (non-condensing) | Weight: approx. 0.8kg Dimensions: 233x157x140mm | Giftbox size: 280x105x194mm |
